| Specification: | Details |
|---|---|
| Brand: | Gigabyte |
| Model: | B860M DS3H WIFI6E |
| Chipset: | Intel B860 Express |
| CPU Socket: | LGA1851 |
| Processor Support: | Intel Core Ultra Processors (Series 2) |
| Form Factor: | Micro-ATX |
| Memory Type: | DDR5 |
| Memory Slots: | 4 × DIMM |
| Maximum Memory: | Up to 256GB |
| Memory Speed Support: | Up to 9066MHz (OC) |
| Graphics Support: | HDMI 2.1 + 2 × DisplayPort 2.1 |
| Expansion Slots: | 1 × PCIe 5.0 x16, 3 × PCIe 4.0 x1 |
| Storage: | 1 × M.2 PCIe 5.0, 1 × M.2 PCIe 4.0, 4 × SATA 6Gb/s |
| LAN: | Realtek 2.5 Gigabit Ethernet |
| Wireless: | Wi-Fi 6E (802.11ax) + Bluetooth 5.3 |
| USB Ports: | USB 3.2 Gen2, USB 3.2 Gen1, USB 2.0 |
| Audio: | Realtek HD Audio (7.1-channel) |
| Rear Ports: | HDMI, 2× DisplayPort, USB ports, RJ-45 LAN, Audio jacks |
| BIOS: | AMI UEFI BIOS |
| Operating System Support: | Windows 11 |
| Warranty: | 3 Years |
