CP PLUS CP-UVK-711M VILLA DOOR STATION & INDOOR MONITOR | IP VIDEO DOOR PHONE SYSTEM
| Specification: | Details |
|---|---|
| Main Processor: | Embedded processor |
| Operating System: | Embedded Linux |
| Button Type: | Mechanical |
| Interoperability: | ONVIF |
| Protocols: | SIP, InstaOn Cloud, IPv4, DNS, RTSP, RTP, TCP, UDP |
| Camera: | 1/4" 1MP CMOS, low illumination, WDR, color/IR |
| Angle of View: | 107° (H), 61° (V), 122° (D) |
| Video Compression: | H.264 |
| Video Resolution: | Main: WVGA / 720P / D1; Sub: CIF / WVGA / QVGA / 1080P / D1 |
| Frame Rate: | PAL 25fps, NTSC 30fps |
| Bitrate: | 256K–4M |
| Light Compensation: | Auto IR |
| D/N Mode: | ICR automatic switch |
| Audio Compression: | G.711a, PCM, AAC |
| Audio Input: | 1 |
| Audio Output: | Built-in speaker |
| Audio Mode: | Two-way talk |
| Audio Enhancement: | Echo suppression, digital noise reduction |
| Unlock Modes: | Card / App / Indoor monitor unlock |
| Card Type: | IC Card |
| Card Capacity: | 10,000 |
| Card Reading Distance: | 3–5 cm |
| Motion Detection: | Supported |
| Auto Snapshot: | Indoor monitor required |
| Leave Messages: | Supported (SD card required) |
| Web Configuration: | Yes |
| RS-485: | 1 |
| Electric Lock: | 1 |
| Exit Button: | 1 |
| Door Status Detection: | 1 |
| Lock Control: | 1 (Normally Closed) |
| Network Port: | 10/100 Mbps (8-core cable) |
| Tamper Alarm: | Yes |
| Casing: | PC + Acrylic |
| Color: | Black |
| Power Supply: | 12V DC 1A / PoE |
| Installation: | Surface mount |
| Accessories: | Brackets + alarm ribbon cable |
| Dimensions: | 135 × 70.4 × 34.4 mm |
| Protection Grade: | IP65 (requires silicone sealant) |
| Operating Temperature: | –30°C to 60°C |
| Humidity: | 10% – 90% RH |
| Altitude: | ≤ 3000m |
| Power Consumption: | ≤1W standby / ≤5W working |
| Weight: | 326 g |
